Applications
Decorative sewing of senior western-style clothes, men and women leisure wear, overcoat, leather clothing, shirts, ties and underwear.
Features:
With computer-controlled system: Sewing speed adjustment, stitch length adjustment, bead size adjustment, bead positive and negative adjustment, semi-stitch adjustment.
It is equipped with needle protector, so the needle doesn’t break during high-speed sewing or thick cloth and turn sewing.
Besides senior bead thread, high-quality common sewing thread also can be used to reduce the cost. By adopting crochet needle design, it can sleeve the thread into the crochet needle easily and conveniently.
Automatic trimming and manual trimming device.
Independent pneumatic presser foot lift and knee presser foot lift.
Easy stitch can be obtained just by adjusting stitch button and loosening stitch handle.
Stitch Chart
| Sewing speed |
420-500 needles/min. |
| Stitch length |
0.5-8mm |
| Stitch type |
1 needle 1 thread (manual stitch) |
| Sewing thread |
Common sewing thread |
| Thread length |
90-120mm |
| Needle model and specification |
780C 16#, 18#, 20#, 23# |
| Presser foot lifting height and mode |
8mm, pneumatic or knee-controlled |
| Lubricating oil |
Bobbin oil |
| Overall dimensions |
128*96*86mm |
| Weight |
170kg |
| Power supply |
220V 50Hz/380V 50Hz |
| Motor power |
0.55KV |
| Air pressure |
5atm |
Note: All product images and technical parameters of the station are for reference only, all with the physical products, if you have any questions, welcome to the customer service personnel detailed consultation.
